| Edition | Restyling |
| Feed | Left-side feed |
| Feed system | Mechanical |
| Working height | 121 ±0.02 mm (4.76 in) |
| Stroke | 30 / 40 mm (1.18 / 1.57 in) |
| Cable cross-section | Max 10 mm² (7 AWG) |
| Terminal pitch | Max 27 mm (1.06 in) |
| Terminal thickness | Max 1.2 mm (0.047 in) |
RSJ offers the same performance as the MRS series, with TOYO JAM connection and dedicated working height. Designed for machines using this standard, it maintains reliability, precise adjustment and ease of maintenance typical of the RS family.
